Nysan Fabric Specifications

GreenScreen® Fabrics



2.3                 Fabric Schedule



2.3.1.             Fabric: “Nysan GreenScreen Balance, Balance/Metallic, Spectra, Spectra Metallic, Vista, Vista Metallic and ECO”



2.3.1.1.          Fabric weight                         8 oz/yd²

2.3.1.2.          Fabric Thickness                   19 mil

2.3.1.3.          Break Strength                       warp 240daN/5cm

                                                                        weft 200daN/5cm

2.3.1.4.          Flame Res.:                            0.0 sec after flame

2.3.1.5.          Fuel contributed value:          0

2.3.1.6.          Average Openness:              ±3% (ECO), ± 7% (Balance), ±10% (Spectra),

                                                                        ± 25% (Vista),

2.3.1.7.          Colorfastness to light:            7/8

2.3.1.8.          Color:                                       Standard Colors

2.3.1.9.          Composition:                          Fabric made with 100% Polyester yarn.

                                                                        Completely PVC Free



2.3.2.                          Fabric:



2.3.2.1.          Waterproof, washable, rot proof.

2.3.2.2.          Flame resistant in accordance with California Flame Test, Title 19 Public Safety, Section 1237.1 small scale test.

2.3.2.3.          Tested in accordance with ASHRAE Standard  74073, "Methods of Measuring Solar-Optical Properties of Materials" and flame spread to NFPA 701-1999 TM#1, Standard Methods of Fire Tests for Flame Resistant Textiles and Films 1999 edition - test method #1 (Small Scale) Toxicity: UPITT Fungal resistance: ASTM G21 Bacterial Resistance, ASTM G22





2.3.3.             Fabric to be chosen from standard range of colors.



End Of Section
